| Category | Specification |
|---|---|
| Type of Bed | Fowler |
| Number of Bed Platform Sections | 4 |
| Backrest Section | Available, welded with MS CRCA tube (14 G) |
| Leg Section | Available, welded with MS CRCA tube (16 G) |
| Mattress Platform | Perforated, CRCA M.S. perforated sheet top, 1.2 mm (18 G) thick |
| Screw Mechanism | Welded with ERW MS tube (18 G) in MS cover made from 16 G ERW tube |
| Manual Adjustments | Backrest and Knee rest through 2 screw systems with thrust bearings, individually maneuvered by 2 handles |
| Backrest Length | ≥ 45% of frame length |
| H-Leg Ends | PVC shoes (for bed without castors) |
| Head & Foot Panels | Detachable by hand without tools, 4 detachable moulded PP with PVC insert panels |
| Saline Rod Provision | 4 locations, SS Telescopic rod, 12 mm dia with 15.87 mm dia × 1.2 mm (18 G) SS tube |
| Hooks in IV Pole | 2 or 4 |
| Syringe Pump Mount | Outer covering tube with knob |
| Finishing & Workmanship | High standard; all corners rounded; burr-free holes |
| Coating for Metal Parts | In-house pretreated / shot blasted, epoxy powder coated (50–100 microns) |
| Handles | Plastic |
| Castors | H-type legs, 600 mm height, 125 mm (5") dia synthetic body castors – 2 with brake, 2 without |
| Urine Bag Holder | Yes |
| Moulded Chart Holder | Yes |
| Collapsible Railing | No |
| Mattress | Not provided |
| Overall Length of Bed | 2050–2100 mm (±5% tolerance) |
| Overall Width of Bed | 900–950 mm (±5% tolerance) |
| Bed Platform Frame Size | 2070 mm L × 910 mm W (±5% tolerance) |
| Mattress Platform Size | 1970 mm L × 790 mm W (±5% tolerance) |
| Buffer Size | 75 mm or 100 mm |
| Buffer to Handle Length | 2275 mm (±5% tolerance) |
| Fixed Height | 600 mm |
| Backrest Dimensions | L: 775–800 mm, W: 775–800 mm |
| Knee Rest Dimensions | L: 400–450 mm, W: 775–800 mm or 750–775 mm |
| Leg Rest Dimensions | L: 550–600 mm, W: 775–800 mm |
| Fixed Section Dimensions | L: 100–150 mm, W: 775–800 mm |
| Raised Backrest Angle | 65° |
| Raised Knee Rest Angle | 40° |
| Bed Frame Tube Size | 60 mm × 30 mm × 1.6 mm (16 G) ERW tube |
| Frame Fitting Dimensions | ERW tubes Ø 31.75 mm × 1.2 mm (18 G), Ø 22.22 mm × 1.2 mm (18 G), MS sheet 3.0 mm (11 G) |
| Rubber Buffers (4 corners) | Ø 75 mm or Ø 100 mm |
| Head & Foot Panel Material | SS Tubular |
| MS Tubular Diameter | 30–50 mm |
| SS Laminated Diameter | 30–50 mm |
| Patient Working Load | 135 kg |
| Safe Working Load | 150 kg |
